Webhook monitoring & debugging

Monitoring webhook health

Key metrics to track

Monitor these metrics to ensure your webhook integration is healthy:

Metric	Description	Alert Threshold
Success Rate	Percentage of webhooks returning 2xx	< 95%
Latency	Time from receipt to response	> 5 seconds
Error Rate	Percentage of 4xx/5xx responses	> 5%
Timeout Rate	Percentage timing out (>30s)	> 1%
Queue Depth	Pending webhooks in processing queue	Growing consistently

Setting up monitoring

Application-level monitoring

const promClient = require('prom-client');

// Create metrics
const webhookCounter = new promClient.Counter({
  name: 'webhook_requests_total',
  help: 'Total number of webhook requests',
  labelNames: ['event', 'status']
});

const webhookLatency = new promClient.Histogram({
  name: 'webhook_processing_seconds',
  help: 'Webhook processing time',
  labelNames: ['event'],
  buckets: [0.1, 0.5, 1, 2, 5, 10, 30]
});

// Middleware to track webhooks
app.post('/webhooks/buttercms', async (req, res) => {
  const startTime = Date.now();
  const { webhook } = req.body;

  try {
    await processWebhook(req.body);

    // Record success
    webhookCounter.inc({ event: webhook.event, status: 'success' });

    res.status(200).json({ received: true });
  } catch (error) {
    // Record failure
    webhookCounter.inc({ event: webhook.event, status: 'error' });

    res.status(500).json({ error: error.message });
  } finally {
    // Record latency
    const duration = (Date.now() - startTime) / 1000;
    webhookLatency.observe({ event: webhook.event }, duration);
  }
});

// Expose metrics endpoint for Prometheus
app.get('/metrics', async (req, res) => {
  res.set('Content-Type', promClient.register.contentType);
  res.end(await promClient.register.metrics());
});

Logging best practices

Structured logging

Use structured logging to make webhook events searchable and analyzable:

const winston = require('winston');

const logger = winston.createLogger({
  level: 'info',
  format: winston.format.combine(
    winston.format.timestamp(),
    winston.format.json()
  ),
  transports: [
    new winston.transports.File({ filename: 'webhooks.log' }),
    new winston.transports.Console()
  ]
});

app.post('/webhooks/buttercms', async (req, res) => {
  const { data, webhook } = req.body;
  const requestId = req.headers['x-request-id'] || crypto.randomUUID();

  // Log incoming webhook
  logger.info('Webhook received', {
    requestId,
    event: webhook.event,
    contentId: data.id,
    contentType: data.page_type || 'post',
    locale: data.locale,
    editor: data.editor,
    timestamp: data.timestamp
  });

  try {
    const result = await processWebhook(req.body);

    logger.info('Webhook processed', {
      requestId,
      event: webhook.event,
      contentId: data.id,
      result,
      processingTime: Date.now() - startTime
    });

    res.status(200).json({ received: true });
  } catch (error) {
    logger.error('Webhook processing failed', {
      requestId,
      event: webhook.event,
      contentId: data.id,
      error: error.message,
      stack: error.stack
    });

    res.status(500).json({ error: 'Processing failed' });
  }
});

Log aggregation

Send logs to a centralized logging service for analysis:

// Datadog example
const { createLogger, format, transports } = require('winston');
const DatadogWinston = require('datadog-winston');

const logger = createLogger({
  transports: [
    new DatadogWinston({
      apiKey: process.env.DATADOG_API_KEY,
      hostname: 'webhook-server',
      service: 'buttercms-webhooks',
      ddsource: 'nodejs',
      ddtags: `env:${process.env.NODE_ENV}`
    })
  ]
});

Debugging webhook issues

Common issues and solutions

Webhooks not being received

Symptoms: No requests arriving at your endpointDebugging steps:

Verify the webhook is enabled in ButterCMS settings
Check the endpoint URL is correct and publicly accessible
Test the endpoint with curl: curl -X POST https://your-endpoint.com/webhooks/buttercms
Check firewall rules and security groups
For local development, ensure ngrok/tunnel is running

Solution: Usually a configuration or network issue. Verify URL accessibility from outside your network.

Webhook showing as failed in ButterCMS

Symptoms: ButterCMS indicates delivery failureDebugging steps:

Check server logs for incoming requests
Verify your endpoint returns 2xx status codes
Ensure response time is under 30 seconds
Check for SSL certificate issues

Solution: Review server logs to identify the specific error. Common causes: slow processing, exceptions, SSL issues.

Webhook arriving but not processing correctly

Symptoms: Request received but actions not happeningDebugging steps:

Log the full webhook payload
Verify payload structure matches expectations
Check event type handling in your switch/if statements
Verify downstream services (cache, database) are accessible

Solution: Add detailed logging at each processing step to identify where the failure occurs.

Duplicate webhook deliveries

Symptoms: Same webhook processed multiple timesDebugging steps:

Check if your endpoint is responding too slowly (causing retries)
Look for timeout errors in logs
Verify idempotency implementation

Solution: Implement idempotency using event IDs or timestamps. Speed up response time.

Content not updating after webhook

Symptoms: Webhook processes but content remains staleDebugging steps:

Verify cache invalidation is actually running
Check CDN cache headers and TTLs
Confirm the correct cache keys are being cleared
Test by manually clearing cache

Solution: Add logging to cache invalidation. Verify CDN is receiving purge requests.

Debug mode

Enable debug mode during development to see full payload details:

const DEBUG = process.env.DEBUG_WEBHOOKS === 'true';

app.post('/webhooks/buttercms', async (req, res) => {
  if (DEBUG) {
    console.log('=== Webhook Debug ===');
    console.log('Headers:', JSON.stringify(req.headers, null, 2));
    console.log('Body:', JSON.stringify(req.body, null, 2));
    console.log('====================');
  }

  // ... rest of handler
});

Testing webhooks locally

Using ngrok

Expose your local server to receive webhooks during development:

# Install ngrok
npm install -g ngrok

# Start your local server
node server.js  # Running on port 3000

# In another terminal, create tunnel
ngrok http 3000

ngrok provides a public URL like https://abc123.ngrok.io that forwards to your local server. Pipedream dashboard showing webhook request

Using webhook testing services

For quick testing without setting up your own endpoint: Webhook.site

# Get a free test URL from https://webhook.site
# Configure this URL in ButterCMS webhook settings
# View incoming requests in real-time on the dashboard

RequestBin

# Create a bin at https://requestbin.com
# Use the provided URL as your webhook endpoint
# Inspect incoming requests

Simulating webhooks

Test your handler with simulated webhook payloads:

// test/webhook.test.js
const request = require('supertest');
const app = require('../app');

describe('Webhook Handler', () => {
  it('should process page.published event', async () => {
    const payload = {
      data: {
        id: 'test-page',
        buttercms_id: 1234,
        page_type: 'landing',
        editor: 'Test User',
        name: 'Test Page',
        timestamp: new Date().toISOString(),
        locale: null,
        status: 'published',
        updated: new Date().toISOString(),
        published: new Date().toISOString(),
        scheduled: null
      },
      webhook: {
        event: 'page.published',
        target: 'https://example.com/webhooks'
      }
    };

    const response = await request(app)
      .post('/webhooks/buttercms')
      .set('X-Webhook-Secret', process.env.WEBHOOK_SECRET)
      .send(payload);

    expect(response.status).toBe(200);
    expect(response.body.received).toBe(true);
  });

  it('should reject unauthorized requests', async () => {
    const response = await request(app)
      .post('/webhooks/buttercms')
      .set('X-Webhook-Secret', 'wrong-secret')
      .send({});

    expect(response.status).toBe(401);
  });
});

Alerting

Setting up alerts

Configure alerts to notify you of webhook issues:

PagerDuty Integration

const axios = require('axios');

async function sendPagerDutyAlert(summary, details) {
  await axios.post('https://events.pagerduty.com/v2/enqueue', {
    routing_key: process.env.PAGERDUTY_ROUTING_KEY,
    event_action: 'trigger',
    payload: {
      summary,
      severity: 'error',
      source: 'webhook-server',
      custom_details: details
    }
  });
}

// Alert on high error rate
if (errorRate > 0.05) {
  await sendPagerDutyAlert(
    'High webhook error rate detected',
    { errorRate, timeWindow: '5 minutes' }
  );
}

Slack Notifications

async function sendSlackAlert(message, details) {
  await axios.post(process.env.SLACK_WEBHOOK_URL, {
    text: message,
    attachments: [{
      color: 'danger',
      fields: Object.entries(details).map(([key, value]) => ({
        title: key,
        value: String(value),
        short: true
      }))
    }]
  });
}

Alert conditions

Set up alerts for these conditions:

Condition	Severity	Action
Error rate > 5%	Warning	Investigate within 1 hour
Error rate > 20%	Critical	Immediate investigation
Endpoint down > 5 min	Critical	Immediate response
Processing time > 20s	Warning	Optimize handler
Queue depth increasing	Warning	Scale processing

Dashboard examples

Grafana dashboard

Create a dashboard to visualize webhook health:

{
  "panels": [
    {
      "title": "Webhook Success Rate",
      "type": "gauge",
      "targets": [{
        "expr": "sum(rate(webhook_requests_total{status='success'}[5m])) / sum(rate(webhook_requests_total[5m])) * 100"
      }]
    },
    {
      "title": "Webhook Latency",
      "type": "graph",
      "targets": [{
        "expr": "histogram_quantile(0.95, rate(webhook_processing_seconds_bucket[5m]))"
      }]
    },
    {
      "title": "Events by Type",
      "type": "piechart",
      "targets": [{
        "expr": "sum by (event) (increase(webhook_requests_total[24h]))"
      }]
    }
  ]
}

Key dashboard panels

Real-time success rate - Shows current webhook health
Latency percentiles - P50, P95, P99 processing times
Events by type - Distribution of webhook events
Error breakdown - Categorized errors for debugging
Processing queue depth - For async processing systems

Troubleshooting checklist

Use this checklist when debugging webhook issues:

Pre-flight checks

Webhook enabled in ButterCMS settings
Correct endpoint URL configured
Correct event types selected
Endpoint is publicly accessible
SSL certificate is valid (for HTTPS)

Endpoint checks

Server is running and healthy
Endpoint accepts POST requests
Endpoint returns 2xx status codes
Response time is under 30 seconds
Authentication is correctly configured

Processing checks

Payload is being parsed correctly
Event type is being handled
Downstream services are accessible
No exceptions being thrown
Idempotency is implemented

Infrastructure checks

Firewall allows inbound traffic
Load balancer is routing correctly
DNS is resolving correctly
No rate limiting blocking requests
Sufficient server resources
